I/O modules
EMC VNX7500 Parts Location Guide 29
Two-port 10-Gb/s optical (w/iSCSI protocol) I/O module
Figure 24 shows the part number label location on the two-port 10-Gb/s optical (w/iSCSI
protocol) I/O module (labeled 10 GbE on the latch handle).
Figure 24 Example of the two-port 10-Gb/s optical (w/iSCSI protocol) I/O module
Table 19 shows the part number label location, part number, description, and whether it
is a FRU or CRU.
Part Number (P/N) Label
CNS-001700
Table 19 Two-port 10-Gb-s optical (w/iSCSI protocol) I/O module part number
Part number label
location
(Figure 24) Part number Description FRU CRU
303-081-105B Two-port 10-Gb/s optical (w/iSCSI
protocol) I/O module
