I/O modules
EMC VNX7500 Parts Location Guide 35
Two-port 10-Gb/s optical I/O module
Figure 22 shows the part number label location on the two-port 10-Gb/s optical or active
Twinax I/O module (labeled 10 GbE v3 on the latch handle).
Figure 30 Example of the two-port 10-Gb/s optical I/O module
Note: This two-port 10-Gb/s optical I/O module requires VNX OE for File version 7.1 or
later.
Table 17 shows the part number label location, part number, description, and whether it
is a FRU or CRU.
Part Number (P/N) Label
CNS-001700
Table 25 Two-port 10-Gb/s optical I/O module part number
Part number label
location
(Figure 22) Part number Description FRU CRU
303-195-100C-01 Two-port 10-Gb/s Optical I/O
module

