EMC VNX Series Parts Location Guide

Small form-factor pluggable (SFP)
EMC VNX7500 Parts Location Guide 37
Types of SFP and SFP+ module latches
SFP transceiver modules can have three types of latching devices to secure the SFP or
SFP+ transceiver in a port socket.
◆ SFP or SFP+ transceiver with a Mylar tab latch.
◆ SFP or SFP+ transceiver with an actuator button latch.
◆ SFP or SFP + transceiver that has a bale-clasp latch.
I/O modules using SFP or SFP+ transceiver modules
In the Block and File VNX7500 platform, the SFP or SFP+ transceiver modules are located
in the ports of the following I/O modules:
◆ Four-port 8-Gb/s Fibre Channel (FC) for 2, 4, and 8 Gb/s speed
◆ Two-port 1-Gb/s copper plus two-port 1-Gb/s optical
◆ Two-port 10-Gb/s optical (labeled 10 GbE iSCSI or 10 GbE v2)
◆ Two-port 10-Gb/s optical
1
(labeled 10 GbE v3)
◆ Two-port 10-Gb/s Fibre Channel over Ethernet (FCoE)
2
Three types of SFP or SFP+ modules that are used in the I/O modules of the Block and File
VNX7500 platform. Figure 31 shows an example of an SFP or SFP+ with a part number
label.
IMPORTANT
Ensure that you correctly match the SFP or SFP+ module type with the I/O module type.
1. The 10 Gb/s module (labeled 10 GbE v3) can also use active twinaxial (Twinax) cables. Twinax is a
type of cable similar to coax, but with two inner conductors instead of one. These cables will be
supplied in lieu of SFPs when so ordered.
2. The FCoE I/O module can also use active twinaxial (Twinax) cables. Twinax is a type of cable
similar to coax, but with two inner conductors instead of one. These cables will be supplied in lieu
of SFPs when so ordered.

EMC VNX Series Specifications

General

Management Interface	Unisphere
Drive Support	SAS, NL-SAS, Flash (SSD)
RAID Levels	RAID 0, 1, 3, 5, 6
Protocols Supported	Fibre Channel, iSCSI, NFS, CIFS
Data Services	Deduplication, Compression, Snapshots, Replication
Processor	Intel Xeon
Operating System	VNX Operating Environment (block), VNX File Operating Environment (file)
