Reference Manual

00809-0200-4420, Rev HC

Section 3: Installation

July 2015

Installation

Section 3 Installation

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 13

Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 14

Remote antenna (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 16

Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 19

3.1 Overview

This section describes how to properly mount the Gateway and make electrical connections,

including electrical wiring, grounding, and host system connections. This section also describes

how to mount the optional remote antenna.

3.1.1 General considerations

The Smart Wireless Gateway may be mounted in any general purpose location. Be sure the

covers are secured tightly to prevent exposure of any electronics to moisture and

contamination.

The Gateway should be mounted in a location that allows convenient access to the host system

network (process control network) as well as the wireless field device network.

3.1.2 Physical description

For dimensional drawing information refer to Appendix B: Product Certifications. The cast

aluminum housing encloses the electronics circuitry of the Gateway. The front of the enclosure

has an upper cover and a junction box cover. The upper cover provides access to the electronics

and radio. The junction box cover provides access to the terminal block.

To open either cover, use a ¼-in. bladed screwdriver to remove the appropriate screw on the

unhinged side of the enclosure.
