Reference Manual
00809-0200-4420, Rev HC
Section 4: Commissioning
July 2015
Commissioning
Note
Only 32-bit versions of the operating systems are supported for AMS Wireless Configurator.
4.3 Software installation
The software can be found on the 2 disk pack, included with the Gateway. Depending on the PC
system configuration, installation may take 30-35 minutes. Installing both disks in order is
recommended. The Security Setup Utility is located on Disk 1. To install the software:
1. Exit/close all Windows programs, including any running in the background, such as
virus scan software.
2. Insert Disk 1 into the CD/DVD drive of the PC.
3. Follow the prompts.
AMS Wireless Configurator is located on Disk 2. To install the software:
1. Exit/close all Windows programs, including any running in the background, such as
virus scan software.
2. Insert Disk 2 into the CD/DVD drive of the PC.
3. Select Install from the menu when the AMS Wireless Configurator setup begins.
4. Follow the prompts.
5. Allow AMS Wireless Configurator to reboot PC.
6. Do not remove the disk from the CD/DVD drive.
7. Installation will resume automatically after login.
8. Follow the prompts.
Table 4-3. Supported Operating Systems
Operating system Version
Windows
™
XP Professional, Service Pack 3
Windows Server 2003 Standard, Service Pack 2
Windows Server 2003 R2 Standard, Service Pack 2
Windows Server 2008 Standard, Service Pack 2
Windows Server 2008 R2 Standard, Service Pack 1
Windows 7 Professional, Service Pack 1
Windows 7 Enterprise, Service Pack 1

Emerson 1420 Specifications

General

Model	1420
Protocols Supported	WirelessHART
Power Supply	24 V DC
Operating Temperature	-40°C to +70°C
Mounting	DIN rail
Hazardous Area Approvals	ATEX, IECEx
Enclosure Rating	IP66
Communication Interface	Ethernet, RS-485
