Reference Manual
00809-0200-4420, Rev HC
Appendix A: Specifications and Reference Data
July 2015
60
Specifications and Reference Data
A.8 Accessories and spare parts
Adapters
J1 CM 20 Conduit Adapters
★
J2 PG 13.5 Conduit Adapters
★
J3
3
/4 NPT Conduit Adapters
★
Antenna options
(11)
WL2 Remote Antenna Kit, 50 ft. (15.2 m) cable, Lightning Arrestor
★
WL3 Remote Antenna Kit, 20 ft. (6.1 m) and 30 ft. (9.1 m) cables, Lightning Arrestor
★
WL4 Remote Antenna Kit, 10 ft. (3.0 m) and 40 ft. (12.2 m) cables, Lightning Arrestor
★
WN2
(12)
High-Gain, Remote Antenna Kit, 25 ft. (7.6m) cable, Lightning Arrestor
Typical model number: 1420 A 2 A3 A 2 N5
1. Single active 10/100 baseT Ethernet port with RJ45 connector.
2. Additional ports disabled.
3. Dual active 10/100 baseT Ethernet ports with RJ45 connectors.
4. Multiple active ports have separate IP addresses, firewall isolation, and no packet forwarding.
5. Convertible to RS232 via adaptor, not included with Gateway.
6. Includes Webserver, Modbus TCP, AMS Ready, HART-IP, and OPC.
7. Options may or may not come with POE. See terminal block configuration for determination if the device is compatible with POE.
8. Requires the selection of Dual Ethernet option code 2.
9. Not available with DeltaV Ready option code 5.
10. Not available with EtherNet/IP option codes 8 and 9
11. The WL2, WL3, WL4, and WN2 options require minor assembly.
12. Not available in all countries.
Table 2. Accessories
Item description
Part number
AMS Wireless SNAP-ON
™
, 1 Gateway License 01420-1644-0001
AMS Wireless SNAP-ON, 5 Gateway Licenses 01420-1644-0002
AMS Wireless SNAP-ON, 10 Gateway Licenses 01420-1644-0003
AMS Wireless SNAP-ON, 5-10 Upgrade Licenses 01420-1644-0004
Serial Port HART Modem and Cables only 03095-5105-0001
USB Port HART Modem and Cables only 03095-5105-0002
Table 1. Smart Wireless Gateway Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
Table 3. Spare Parts
Item description
Part number
Spare Kit, WL2 Replacement
(1)
, Remote Antenna, 50 ft. (15,2 m) Cable, and Lightning Arrestor 01420-1615-0302
Spare Kit, WL3 Replacement
(1)
, Remote Antenna, 20/30 ft. (6,1/9,1 m) Cables, and Lightning Arrestor 01420-1615-0303
Spare Kit, WL4 Replacement
(1)
, Remote Antenna, 10/40 ft. (3,0/12,2 m) Cables, and Lightning Arrestor 01420-1615-0304
Spare Kit, WN2 Replacement
(1)
, High Gain, Remote Antenna, 25 ft. (7.6 m) Cable, and Lightning Arrestor
(2)
01420-1615-0402
1. Can not upgrade from integral to remote antenna.
2. Not available in all countries.
