October 2015
Service Instructions
127072E Rev. C
13
Section 3: Actuator Reassembly
Actuator Reassembly
NOTE:
The spherical side of the washer will go on the extension rod assembly facing the head of
the extension rod assembly.
3�2�11 Install extension rod assembly (9-50) into guide block (1-30) and up against the
rst spherical washer (9-40).
3�2�12 Install extension retainer nut (9-60) over extension rod assembly (9-50) and screw
into guide block (1-30).
3�2�13 Tighten extension retainer nut assembly (9-60) until extension rod assembly (9-
50) is immovable. Back off the extension retainer nut assembly (9-60) just enough
to allow for extension rod assembly (9-50) to move freely.
NOTE:
Consult Houston, Texas Bettis Service Coordinator for “yoke bearing, yoke pin bearing or
yoke/guide block bushing installation information."
3�2�14 If the two yoke bearings (2-40) are being replaced, install new bearing into housing
cover (1-20) and housing (1-10).
NOTE:
The yoke bearing (2-40) must be pressed t into housing (1-10) and housing cover (1-20).
Install the yoke bearings with the bearing seam located 45 ±5 degrees from the yoke arm
slot when yoke (1-70) is rotated to its full clockwise position.
3�2�15 If the two yoke pin thrust bearings (2-10) are being replaced install new bearing
into housing cover (1-20) and housing (1-10).
3�2�16 Lubricate two yoke/guide block bushings (2-30) and install onto top and bottom
sides of guide block (1-30).
NOTE:
The guide block (1-30) should be already preassembled with extension rod assembly and
associated parts assembled in the guide block.
3�2�17 Install guide block (1-30), with yoke/guide block bushings (2-30), between arms of
yoke (1-70).
3�2�18 Install O-ring seal (2-50) into inner diameter O-ring groove in the bottom of
housing (1-10).
3�2�19 Coat the bearing surfaces of the yoke (1-70) with lubricant and install into
housing (1-10).
3�2�20 Align hole in guide block (1-30) with the matching holes in the two yoke/guide
block bushings (2-30) and the slots in the arms of yoke (1-70).
