Alarm "Conguration n°"
Section 4: Alarm "Conguration n°"
Table 1. Stroke Limits and Torque Setup
Actuator Setup
Obj n° Value Function Description
102 CW Close direction CW, CCW
100 Off Close limit type Torque, position
101 Off Open limit type Torque, position
506 70 Closing torque From 40 to 100%
505 75 Opening torque From 40 to 100%
510 60 Breakout in closing From 40 to 100%
511 40 Peak run in closing From 40 to 100%
512 80 Ending in closing From 40 to 100%
513 90 Breakout zone in closing From 0 to 100%
514 10 Ending zone in closing From 0 to 100%
515 90 Breakout in opening From 40 to 100%
516 40 Peak run in opening From 40 to 100%
517 80 Ending in opening From 40 to 100%
518 20 Breakout zone in opening From 0 to 100%
519 80 Ending zone in opening From 0 to 100%
Table 2. ESD Setup
Actuator Setup
Obj n° Value Function Description
600 Off ESD action
Off, close, open, stay put, go to
position %
601 50 ESD position From 0 to 100
605 ESD<thermostat ESD and motor thermostat alarm ESD<thermostat, ESD>thermostat
606 ESD<local stop ESD and torque alarm ESD<torque limit, ESD>torque limit
607 ESD<local stop ESD and local stop ESD<local stop, ESD>local stop
608 ESD<local selector ESD and local selector in LOCAL ESD<local selector, ESD>local selector
609 ESD<local selector in OFF ESD and local selector in OFF
ESD<local selector in OFF,
ON=ESD>local selector in OFF
611 ESD<2 speed timer ESD and 2-speed timer ESD<2-speed timer, ESD>2-speed timer
602 Present ESD signal type
ESD carried out: with signal absent or
with signal present
NOTICE
The functions related to EFS and F01 are not applicable to XTE3000.
