Installation, Operation and Maintenance Manual
MDE 257 Rev. 1
February 2022
37
Section 8: Connector Base Card
Connector Base Card
Section 8: Test Point and Connector
Base Card
Terminal
Board
Power Card
Position
encoder
Local
controls
Motor
temperature
Speed
sensor
Figure 9
