Emerson Bettis XTE3000 Maintenance Instruction

Installation, Operation and Maintenance Manual
MDE 257 Rev. 1
February 2022
25
Alarm "Conguration n°"
Section 4: Alarm "Conguration n°"
Table 25. Reserved
Actuator Setup
Obj n° Value Function Description
148 Icon SW type XTE, F01
173 I24 V4 Terminal board type I24 V4, 5 relays, 8/9 relays, 12 relays, I24 Gold PR
105 Mask Additional variables Mask, view
4 Auto Backlight Auto, on
134 1.5 Reversal delay Reversal delay, from 0 to 5.5 s (standard > 1)
146 200 Volt span bit Voltage span in bit, can only be read
720 650 4 mA in Bit corresponding to 4 mA input
721 3500 20 mA in Bit corresponding to 20 mA input
722 650 4 mA out Bit corresponding to 4 mA output
723 3500 20 mA out bit corresponding to 20 mA output
161 451 Curr sens 2 A Bits when current is 2 A
162 382 Curr sens 3.5 A Bits when current is 3.5 A
163 387 Curr sens 7 A Bits when current is 7 A
164 443 Curr sens 15 A Bits when current is 15 A
165 441 Curr sens 30 A Bits when current is 30 A
424 10 Speed filter From 0 to 255
170 1 Base heater reference
°C reference of heater on base card,
from -40 to 50 °C
171 -2 LCD heater reference
°C reference of heater on diplay card,
from -40 to 50 °C
172 -1 Terminal board heater reference
°C reference of heater on terminal board,
from -40 to 50 °C
707 Disable Sleep mode Enable, disable SLEEP function
238 Off MR in SLEEP On/off of monitor relay in sleep mode
576 Standard Torque function Mode to evaluate torque, standard or advanced
533 Standard Interlock mode Standard or advanced (local+interlock OP/CL)
420 Disable New FW
Disable or enable, set to "enable" to download a new
firmware.
429 Disable Serial CMD
Disable or enable OP/CL/ST commands by BLT or serial
RS232
430 Disable Loc/Rem Enable or disable "Local + Remote" control mode
431 s/n° Bluetooth code Select Bluetooth code or valve tag
815 75 EFS-duty %
Duty of EFS clutch (used only in EFS actuator). Not used
for XTE3000.
803 Close Spring action Actuator movement under
804 On EFS electrical CMD
Enable/disable of electrical CMD in direction of safe
action. Not used for XTE3000.
805 PST ESD input mode
Selector of ESD input of actuator, PST or EFS (electrical)
CMD. Not used for XTE3000.
806 Absent EFS signal type
Option Absent/present in case of ESD input used as EFS
CMD. Not used for XTE3000.
133 0 CMD-Filter From 0 to 30 filter of OP/CL/ST commands signals
135 0 ESD-INT Filter From 0 to 30 filter of ESD/INT commands signal
