Emerson Bettis XTE3000 Maintenance Instruction

February 2022
Installation, Operation and Maintenance Manual
MDE 257 Rev. 1
24
Alarm "Conguration n°"
Section 4: Alarm "Conguration n°"
Actuator Setup
Obj n° Value Function Description
405
Open
limit
DIN 6
Open limit, close limit, position >=%, position <=%,
closing, opening, running, blinker, mid-travel, local
selected, remote selected, local stop on, ESD/PST-efs,
manual operation (handwheel), motor over temperature
alarm, over torque alarm, over torque alarm in OP, over
torque alarm in CL, valve jammed alarm in OP, valve
jammed alarm in CL, valve jammed alarm, low battery
alarm, warnings, mid travel alarms, EFS in manual, PST
failed, Mains only As8, EFS mid-travel, INTER/PST-icon, EFS
coil OFF
411 50 DIN 1 pos% Position% if DIN 1 = position >= or <=
412 50 DIN 2 pos% Position% if DIN 2 = position >= or <=
413 50 DIN 3 pos% Position% if DIN 3 = position >= or <=
414 50 DIN 4 pos% Position% if DIN 4 = position >= or <=
415 50 DIN 5 pos% Position% if DIN 5 = position >= or <=
416 50 DIN 6 pos% Position% if DIN 6 = position >= or <=
417 1 Hart node Hart address, from 0 to 63
428 1 Profibus redundant node Profibus address of backup slave, from 1 to 126
425 1 Hart device number Hart serial number from 0 to 116777200, 3 bytes
426 0 Hart configuration changes
Number of Hart configuration changes, visible only from
node report menu
Table 24. Restricted
Actuator Setup
Obj n° Value Function Description
160 1.2 Speed bypass Speed bypass time. Set value from 0 to 25.5 (standard >1)
508 5 Torque stop zone
Torque stop zone in % of position, from 0 to 20% in OP
(or 100 to 80% in CL)
115
1 (XTE-EFS)
4 (F01)
Direction test
Direction test (F01), from 0 to 255 (standard 4), for XTE/EFS
standard 1
145 400 Voltage span
Voltage span, from 0 to 1000 (change at least 1 V to enter
new value)
107 Off 1 P.man Disabled, enabled
116 Base Hardware configuration
Base, lonworks, modbus, profibus-DPV0, modbus_m, FF,
hart, profibus-DPV1, profibus-DPV1r
700 Disabled Positioner Disabled, enabled
704 4 - 20 mA Position request type From 4 - 20 mA input or from bus
703 Disabled Failsafe enable Disabled, enabled
421 Torque Bus An. Out. Torque, torque + temperature (only FF)
706 Absent Ain/Aout card enable Present, absent
705 Disable EXT "Bluetooth" enable Enable, disable
719 Disable IrDA enable Enable, disable
410 I24 Bus card protocol
Communication protocol among base and bus cards,
I20 or I24
422 Disable PID (not available) Disable, enable (always disabled)
