Emerson Bettis XTE3000 Maintenance Instruction

Installation, Operation and Maintenance Manual
MDE 257 Rev. 1
February 2022
23
Alarm "Conguration n°"
Section 4: Alarm "Conguration n°"
Table 23. Bus Control
Actuator Setup
Obj n° Value Function Description
408 Off Status of termination channel 1 Off, On
409 Off Status of termination channel 2 Off, On
419 Auto Mode Channel_1, channel_2, auto
418 Auto Modbus baud rate Auto, 600, 1200, 2400, 4800, 9600, 19200, 38400
406 One Modbus parity None, even, odd
407 1 Modbus node Modbus address, from 0 to 246
423 1 Profibus node Profibus address, from 1 to 126
400
Open
limit
DIN 1
Open limit, close limit, position >=%, position <=%,
closing, opening, running, blinker, mid-travel, local
selected, remote selected, local stop on, ESD/PST-efs,
manual operation (handwheel), motor over temperature
alarm, over torque alarm, over torque alarm in OP, over
torque alarm in CL, valve jammed alarm in OP, valve
jammed alarm in CL, valve jammed alarm, low battery
alarm, warnings, mid travel alarms, EFS in manual, PST
failed, Mains only As8, EFS mid-travel, INTER/PST-icon, EFS
coil OFF
401
Open
limit
DIN 2
Open limit, close limit, position >=%, position <=%,
closing, opening, running, blinker, mid-travel, local
selected, remote selected, local stop on, ESD/PST-efs,
manual operation (handwheel), motor over temperature
alarm, over torque alarm, over torque alarm in OP, over
torque alarm in CL, valve jammed alarm in OP, valve
jammed alarm in CL, valve jammed alarm, low battery
alarm, warnings, mid travel alarms, EFS in manual, PST
failed, Mains only As8, EFS mid-travel, INTER/PST-icon, EFS
coil OFF
402
Open
limit
DIN 3
Open limit, close limit, position >=%, position <=%,
closing, opening, running, blinker, mid-travel, local
selected, remote selected, local stop on, ESD/PST-efs,
manual operation (handwheel), motor over temperature
alarm, over torque alarm, over torque alarm in OP, over
torque alarm in CL, valve jammed alarm in OP, valve
jammed alarm in CL, valve jammed alarm, low battery
alarm, warnings, mid travel alarms, EFS in manual, PST
failed, Mains only As8, EFS mid-travel, INTER/PST-icon, EFS
coil OFF
403
Open
limit
DIN 4
Open limit, close limit, position >=%, position <=%,
closing, opening, running, blinker, mid-travel, local
selected, remote selected, local stop on, ESD/PST-efs,
manual operation (handwheel), motor over temperature
alarm, over torque alarm, over torque alarm in OP, over
torque alarm in CL, valve jammed alarm in OP, valve
jammed alarm in CL, valve jammed alarm, low battery
alarm, warnings, mid travel alarms, EFS in manual, PST
failed, Mains only As8, EFS mid-travel, INTER/PST-icon, EFS
coil OFF
404
Open
limit
DIN 5
Open limit, close limit, position >=%, position <=%,
closing, opening, running, blinker, mid-travel, local
selected, remote selected, local stop on, ESD/PST-efs,
manual operation (handwheel), motor over temperature
alarm, over torque alarm, over torque alarm in OP, over
torque alarm in CL, valve jammed alarm in OP, valve
jammed alarm in CL, valve jammed alarm, low battery
alarm, warnings, mid travel alarms, EFS in manual, PST
failed, Mains only As8, EFS mid-travel, INTER/PST-icon, EFS
coil OFF
