Emerson Bettis XTE3000 Maintenance Instruction

February 2022
Installation, Operation and Maintenance Manual
MDE 257 Rev. 1
22
Alarm "Conguration n°"
Section 4: Alarm "Conguration n°"
Table 18. Miscellaneous
Actuator Setup
Obj n° Value Function Description
531 Standard Torque mode Standard, 3 points
103 Absent Alkaline battery Present, absent
6 1.01.01 Present date Present date, dd.mm.yy
7 0.00.00 Present time Present time, hh.mm.ss
507 20 Torque bypass From 0 to 20, % of position
144 100 Jammed valve time From 0 to 100 s
235 Enabled Bluetooth Enabled, disabled
Table 19. Fail-Safe
Actuator Setup
Obj n° Value Function Description
715 Off Action Off, close, open, stay put, go to position %
717 10 Delay
Delay before than fail action takes place,
from 0 to 255 s
716 50 Position
Position % of failsafe if action is "go to position %",
from 0 to 100
Table 20. Interlocks
Actuator Setup
Obj n° Value Function Description
708 Off Interlock in opening Absent, present, off
709 Off Interlock in closing Absent, present, off
Table 21. Positioner
Actuator Setup
Obj n° Value Function Description
710 0.5 Dead band From "position resolution" to 25.5%
711 6 Motion inhibit Motion inhibit time in s, from 1 to 255
712 0 % min Standard 0
713 100 % max Standard 100
701 4 mA = CL Polarity of input 4 - 20 mA 4 mA = CL, 20 mA = OP
Table 22. Out 4 - 20 mA
Actuator Setup
Obj n° Value Function Description
702 4 mA = CL Polarity of output 4 - 20 mA 4 mA = CL, 20 mA = OP
718 Position Output signal Position mA, torque mA
