Emerson Bettis XTE3000 Maintenance Instruction

Installation, Operation and Maintenance Manual
MDE 257 Rev. 1
February 2022
21
Alarm "Conguration n°"
Section 4: Alarm "Conguration n°"
Table 15. AS10 Relay
Actuator Setup
Obj n° Value Function Description
1205 Open limit AS10 condition
Open limit, close limit, position >=%, position <=%, closing,
opening, running, blinker, mid-travel, local selected, remote
selected, local stop on, ESD/PST-efs, manual operation
(handwheel), motor over temperature alarm, over torque
alarm, over torque alarm in OP, over torque alarm in CL, valve
jammed alarm in OP, valve jammed alarm in CL, valve jammed
alarm, low battery alarm, warnings, mid travel alarms, EFS
in manual, PST failed, Mains only As8, EFS mid-travel, INTER/
PST-icon, EFS coil OFF
1215 20 AS10 position% Position% if AS10 condition is position >=% or <=%
1225 Make AS10 contact Make, break
Table 16. AS11 Relay
Actuator Setup
Obj n° Value Function Description
1206 Open limit AS11 condition
Open limit, close limit, position >=%, position <=%, closing,
opening, running, blinker, mid-travel, local selected, remote
selected, local stop on, ESD/PST-efs, manual operation
(handwheel), motor over temperature alarm, over torque
alarm, over torque alarm in OP, over torque alarm in CL, valve
jammed alarm in OP, valve jammed alarm in CL, valve jammed
alarm, low battery alarm, warnings, mid travel alarms, EFS
in manual, PST failed, Mains only As8, EFS mid-travel, INTER/
PST-icon, EFS coil OFF
1216 20 AS11 position% Position% if AS11 condition is position >=% or <=%
1226 Make AS11 contact Make, break
Table 17. 2-Speed Timer
Actuator Setup
Obj n° Value Function Description
51 Off Status Off=disable timer in CL, on=enable
55 2 On time in closing From 2 to 200
56 2 Off time in closing From 2 to 200
53 0 Start position in closing % of position where timer operation starts. From 0 to 100
54 100 Stop position in closing % of position where timer operation ends. From 0 to 100
52 Off Status Off=disable timer in OP, on=enable
59 2 On time in opening From 2 to 200
60 2 Off time in opening From 2 to 200
57 0 Start position in opening % of position where timer operation starts. From 0 to 100
58 100 Stop position in opening % of position where timer operation ends. From 0 to 100
