Emerson Bettis XTE3000 Maintenance Instruction

February 2022
Installation, Operation and Maintenance Manual
MDE 257 Rev. 1
20
Alarm "Conguration n°"
Section 4: Alarm "Conguration n°"
Table 12. AS7 Relay
Actuator Setup
Obj n° Value Function Description
1202 Open limit AS7 condition
Open limit, close limit, position >=%, position <=%, closing,
opening, running, blinker, mid-travel, local selected, remote
selected, local stop on, ESD/PST-efs, manual operation
(handwheel), motor over temperature alarm, over torque
alarm, over torque alarm in OP, over torque alarm in CL, valve
jammed alarm in OP, valve jammed alarm in CL, valve jammed
alarm, low battery alarm, warnings, mid travel alarms, EFS
in manual, PST failed, Mains only As8, EFS mid-travel, INTER/
PST-icon, EFS coil OFF
1212 20 AS7 position% Position% if AS7 condition is position >=% or <=%
1222 Make AS7 contact Make, break
Table 13. AS8 Relay
Actuator Setup
Obj n° Value Function Description
1203 Open limit AS8 condition
Open limit, close limit, position >=%, position <=%, closing,
opening, running, blinker, mid-travel, local selected, remote
selected, local stop on, ESD/PST-efs, manual operation
(handwheel), motor over temperature alarm, over torque
alarm, over torque alarm in OP, over torque alarm in CL, valve
jammed alarm in OP, valve jammed alarm in CL, valve jammed
alarm, low battery alarm, warnings, mid travel alarms, EFS
in manual, PST failed, Mains only As8, EFS mid-travel, INTER/
PST-icon, EFS coil OFF
1213 20 AS8 position% Position% if AS8 condition is position >=% or <=%
1223 Make AS8 contact Make, break
Table 14. AS9 Relay
Actuator Setup
Obj n° Value Function Description
1204 Open limit AS9 condition
Open limit, close limit, position >=%, position <=%, closing,
opening, running, blinker, mid-travel, local selected, remote
selected, local stop on, ESD/PST-efs, manual operation
(handwheel), motor over temperature alarm, over torque
alarm, over torque alarm in OP, over torque alarm in CL, valve
jammed alarm in OP, valve jammed alarm in CL, valve jammed
alarm, low battery alarm, warnings, mid travel alarms, EFS
in manual, PST failed, Mains only As8, EFS mid-travel, INTER/
PST-icon, EFS coil OFF
1214 20 AS9 position% Position% if AS9 condition is position >=% or <=%
1224 Make AS9 contact Make, break
