Alarm "Conguration n°"
Section 4: Alarm "Conguration n°"
Table 9. AS4 Relay
Actuator Setup
Obj n° Value Function Description
223 Close limit AS4 condition
Open limit, close limit, position >=%, position <=%, closing,
opening, running, blinker, mid-travel, local selected, remote
selected, local stop on, ESD/PST-efs, manual operation
(handwheel), motor over temperature alarm, over torque
alarm, over torque alarm in OP, over torque alarm in CL, valve
jammed alarm in OP, valve jammed alarm in CL, valve jammed
alarm, low battery alarm, warnings, mid travel alarms, EFS
in manual, PST failed, Mains only As8, EFS mid-travel, INTER/
PST-icon, EFS coil OFF
243 20 AS4 position% Position% if AS4 condition is position >=% or <=%
234 Make AS4 contact Make, break
Table 10. AS5 Relay
Actuator Setup
Obj n° Value Function Description
1200 Open limit AS5 condition
Open limit, close limit, position >=%, position <=%, closing,
opening, running, blinker, mid-travel, local selected, remote
selected, local stop on, ESD/PST-efs, manual operation
(handwheel), motor over temperature alarm, over torque
alarm, over torque alarm in OP, over torque alarm in CL, valve
jammed alarm in OP, valve jammed alarm in CL, valve jammed
alarm, low battery alarm, warnings, mid travel alarms, EFS
in manual, PST failed, Mains only As8, EFS mid-travel, INTER/
PST-icon, EFS coil OFF
1210 20 AS5 position% Position% if AS5 condition is position >=% or <=%
1220 Make AS5 contact Make, break
Table 11. AS6 Relay
Actuator Setup
Obj n° Value Function Description
1201 Open limit AS6 condition
Open limit, close limit, position >=%, position <=%, closing,
opening, running, blinker, mid-travel, local selected, remote
selected, local stop on, ESD/PST-efs, manual operation
(handwheel), motor over temperature alarm, over torque
alarm, over torque alarm in OP, over torque alarm in CL, valve
jammed alarm in OP, valve jammed alarm in CL, valve jammed
alarm, low battery alarm, warnings, mid travel alarms, EFS
in manual, PST failed, Mains only As8, EFS mid-travel, INTER/
PST-icon, EFS coil OFF
1211 20 AS6 position% Position% if AS6 condition is position >=% or <=%
1221 Make AS6 contact Make, break
