Emerson Bettis XTE3000 Maintenance Instruction

February 2022
Installation, Operation and Maintenance Manual
MDE 257 Rev. 1
18
Alarm "Conguration n°"
Section 4: Alarm "Conguration n°"
Table 6. AS1 Relay
Actuator Setup
Obj n° Value Function Description
220 Open limit AS1_condition
Open limit, close limit, position >=%, position <=%, closing,
opening, running, blinker, mid-travel, local selected, remote
selected, local stop on, ESD/PST-efs, manual operation
(handwheel), motor over temperature alarm, over torque
alarm, over torque alarm in OP, over torque alarm in CL, valve
jammed alarm in OP, valve jammed alarm in CL, valve jammed
alarm, low battery alarm, warnings, mid travel alarms, EFS
in manual, PST failed, Mains only As8, EFS mid-travel, INTER/
PST-icon, EFS coil OFF
240 20 AS1 position% Position% if AS1 condition is position >=% or <=%
231 Make AS1 contact Make, break
Table 7. AS2 Relay
Actuator Setup
Obj n° Value Function Description
221 Close limit AS2 condition
Open limit, close limit, position >=%, position <=%, closing,
opening, running, blinker, mid-travel, local selected, remote
selected, local stop on, ESD/PST-efs, manual operation
(handwheel), motor over temperature alarm, over torque
alarm, over torque alarm in OP, over torque alarm in CL, valve
jammed alarm in OP, valve jammed alarm in CL, valve jammed
alarm, low battery alarm, warnings, mid travel alarms, EFS
in manual, PST failed, Mains only As8, EFS mid-travel, INTER/
PST-icon, EFS coil OFF
241 20 AS2 position% Position% if AS2 condition is position >=% or <=%
232 Make AS2 contact Make, break
Table 8. AS3 Relay
Actuator Setup
Obj n° Value Function Description
222 Open limit AS3 condition
Open limit, close limit, position >=%, position <=%, closing,
opening, running, blinker, mid-travel, local selected, remote
selected, local stop on, ESD/PST-efs, manual operation
(handwheel), motor over temperature alarm, over torque
alarm, over torque alarm in OP, over torque alarm in CL, valve
jammed alarm in OP, valve jammed alarm in CL, valve jammed
alarm, low battery alarm, warnings, mid travel alarms, EFS
in manual, PST failed, Mains only As8, EFS mid-travel, INTER/
PST-icon, EFS coil OFF
242 20 AS3 position% Position% if AS3 condition is position >=% or <=%
233 Make AS3 contact Make, break
