Installation, Operation and Maintenance Manual
MDE 257 Rev. 1
February 2022
27
Alarm "Conguration n°"
Section 4: Alarm "Conguration n°"
Table 34. Power Supply
Nameplate
Obj n° Value Function Description
111 AC3ph Power type AC3ph, AC1ph, DC
110 400 Supply voltage value Nominal voltage supply value
104 50 Hz Supply voltage frequency 50 Hz, 60 Hz
Table 35. Motor Data
Nameplate
Obj n° Value Function Description
113 AC3ph Motor supply type AC3ph, AC1ph, DC
122 0.5 Motor nominal power (rating) KW, from 0 to 99.9
123 0.3
Motor current In
(motor nominal current)
A, from 0 to 99.9
124 0.4
Motor current Is
(seating current)
A, from 0 to 99.9
125 0.5
Motor current Icc
(locked rotor current)
A, from 0 to 999,9
126 S2-15 min. Motor service
S2-15 min., S4-25%-60start/h, S4-25%-200start/h,
S4-25%-600start/h, S4-25%-1200start/h,
S4-25%-3600start/h, S9 continuous
112 6 Motor poles From 0 to 32
427 SM32 Motor code Max. 28 characters
577 10 Gears ratio Reduction ratio of gears, from 1 to 1000
Table 36. Test Date
Nameplate
Obj n° Value Function Description
306 17.04.04 Test date Factory test date (dd.mm.yy)
Table 37. Revision
Nameplate
Obj n° Value Function Description
114 4 HW revision Hardware revision
5 2.03 SW H8 Software revision H8 base card, read only from XTE firmware
8 1.10 SW PIC Software revision PIC base card, read only from XTE firmware
