Alarm "Conguration n°"
Section 4: Alarm "Conguration n°"
Table 38. Torque Sensor
Nameplate
Obj n° Value Function Description
536 700 F01tor op 100%
Value of potentiometer at 100% of opening torque, in F01.
Not used for XTE3000
537 600 F01tor op 50%
Value of potentiometer at 50% of opening torque, in F01.
Not used for XTE3000
538 400 F01tor op 50%
Value of potentiometer at 50% of closing torque, in F01.
Not used for XTE3000
539 300 F01tor op 100%
Value of potentiometer at 100% of closing torque, in F01.
Not used for XTE3000
540 500 I2tor op 0% +5% Opening speed with torque 0% and voltage +5% of nominal
541 450 I2tor op 40% +5% Opening speed with torque 40% and voltage +5% of nominal
542 400 I2tor op 70% +5% Opening speed with torque 70% and voltage +5% of nominal
543 300 I2tor op 100% +5% Opening speed with torque 100% and voltage +5% of nominal
577 10 Gears ratio Reduction ratio of gears, from 1 to 1000
545 440 I2tor op 40% -5% Opening speed with torque 40% and voltage -5% of nominal
546 390 I2tor op 70% -5% Opening speed with torque 70% and voltage -5% of nominal
547 290 I2tor op 100% -5% Opening speed with torque 100% and voltage -5% of nominal
548 600 I2tor cl 0% +5% Closing speed with torque 0% and voltage +5% of nominal
549 550 I2tor cl 40% +5% Closing speed with torque 40% and voltage +5% of nominal
550 500 I2tor cl 70% +5% Closing speed with torque 70% and voltage +5% of nominal
551 450 I2tor cl 100% +5% Closing speed with torque 100% and voltage +5% of nominal
553 540 I2tor cl 40% -5% Closing speed with torque 40% and voltage -5% of nominal
554 490 I2tor cl 70% -5% Closing speed with torque 70% and voltage -5% of nominal
555 430 I2tor cl 100% -5% Closing speed with torque 100% and voltage -5% of nominal
580 400 I2tor voltage Voltage of torque calibration, from 0 to 1000 V
106 50 Hz I2tor freq. 50 Hz, 60 Hz, frequency of torque calibration
509 2 I2tor Ktemp Temperature compensation, from 1 to 20
994 70 Torque-set CL (XTE) Value of torque set in factory
995 70 Torque-set OP (XTE) Value of torque set in factory
996 70 Torque-set CL (F01) Value of torque set in factory. Not used for XTE3000
997 70 Torque-set OP (F01) Value of torque set in factory. Not used for XTE3000
Table 39.
Valve Data
Obj n° Value Function Description
154 f5000 Valve tag name Max. 28 characters
156 q234f Valve serial number Max. 28 characters
990 - Manufacturer Max. 28 characters
991 - Break-OP torque Max. 28 characters
992 - Max. stem thrust Max. 28 characters
993 - Flange type Max. 28 characters
542 400 I2tor op 70% +5% Opening speed with torque 70% and voltage +5% of nominal
543 300 I2tor op 100% +5% Opening speed with torque 100% and voltage +5% of nominal
996 70 Torque-set CL (F01) Value of torque set in factory. Not used for XTE3000
997 70 Torque-set OP (F01) Value of torque set in factory. Not used for XTE3000
