Daniel models 3415, 3416 and 3417 meter specificationsTable 1-1:
Daniel 3415, 3416 and 3417 meter specifications
Model 3417
AGA 9 / ISO 17089 Flow rate values (US Customary
Units)
Meter
size (IN) 8 to 24 30 36 42
Q
min
(ft/
s)
1.7 1.7 1.7 1.7
Q
t
(ft/s) 10 8.5 7.5 CF *
Q
max
(ft/
s)
100 85 7.5 CF *
(*) CF = consult factory
Body and Flange Sizes and Pressure
rating range
U.S. Customary Units - Meter sizes 8, 10, 12, 16, 20, 24, 30,
and 36 (inches)
• ANSI pressure classes 300, 600, 900and 1500(per AN-
SIB16.5)
• Carbon Steel
• 316 Stainless Steel
Metric Units - Meter sizes DN - 200, 250, 300, 400, 500,
600, 750, 900
• PN 50, 100, 150, 200
• Carbon Steel
• 316 Stainless Steel
Maximum Pressures
• Dependent on operating temperature
Meter bore
• Schedule 20, 30, 40, 60, 80, 100, 120, 140, 160, STD,
XS, LW
Flanges types ANSI classes - 300, 600, 900 and 1500 (per ANSI B16.5)
Specific gravity 0.35 to 1.50
Accuracy Limits Models 3415, 3416 and 3417 are AGA 9 compliant with ac-
curacy limits
• ± 1% without a flow calibration (10” and smaller line
sizes)
• ± 0.7% without a flow calibration (12” and larger line
sizes)
• ±0.1% with a flow calibration
Minimum operating pressure 100 psig (7 bar)
