Emerson Dixell XV300K Series User Manual

1592016130 XV300K EN MASTER r1.1 16.06.2015
XV300K
10/26
9 CONTROL PANEL
The control panel visualizes in real time the inputs and outputs of the adjuster and allows setting the parameters. It is
provided with a back-illuminated LCD/OLED display and with four keys described below.
(UP) Goes to the previous visualization / increases a
(DOWN) Goes to the next visualization / decreases a
parameter
(ENT) Enters the menu and the parameters / confirms
the variation of a parameter
(ESC) Escapes from the menu and the parameters /
cancels a variation of parameter
10 STATE MENU
After the device is powered on the display visualizes the firmware versions of the device and the keyboard. Then, if
no error occurs, the first status window will appear, where temperatures or the pressure registered by input 1 are
visualised:
RUN in operating state
FLT in block state
RDY if in Stop state
The cycle used for the adjusting is visualized at the right bottom: CO (COOL) or HEA (HEAT) followed by the
number 1 or 2 for first or second cycle.
In this mode:
 Press the key to slide the state menu downward;
 Press the key to slide the state menu upward.
10.1 STATE WINDOW BOXES
Defines the output voltage/speed. The percentage value refers from 0 to
98% of power voltage
Defines the operating mode of the adjuster:
Chiller, Dry Cooler or Slave.
This is a display-only parameter. To edit it go to the basic settings menu
inside the “PREIMPO [IB]” menu
MODE
“chiller”
*
OUTPUT
67
%
DRY COOLER
Temp.1
21.3 °C
[CO1]
[RUN]
CHILLER
Press.1
20.3 bar
[CO1]
[RUN]
