Emerson Dixell XV300K Series User Manual

1592016130 XV300K EN MASTER r1.1 16.06.2015
XV300K
3/26
1 READ CAREFULLY
CAUTION! BEFORE INSTALLING THE XV300K MASTER CONTROLLER READ CAREFULLY
THE MANUAL AND FOLLOWS ALL THE INSTRUCTIONS HEREIN. WITH POWERED
CONTROLLER DO NOT TOUCH THE INNER ELECTRICAL PARTS IN ANY CASE. IN
COMPLIANCE WITH THE EU RULES AND THE EMC DIRECTIVES, PLEASE REMIND THAT THE
XV300K CONTROLLER IS DESIGNED TO BE INCORPORATED ON MACHINES OR
INTEGRATED ON CONTROL PANELS AND THEREFORE IS TO BE CONSIDERED AS A COMPONENT. THE
MACHINE INSTALLATOR SHALL PROVIDE FOR THE GUARANTEE OF COMPLIANCE OF ITS EQUIPMENT TO
SUCH RULES. IN THE EVENT THAT THE CONTROLLER FAILS TO OPERATE AND CAUSES DAMAGES TO
THINGS OR PERSONS IT SHALL BE THE INSTALLER’S RESPONSIBILITY TO PROVIDE SAFETY DEVICES OR
SYSTEMS TO PROTECT OR WARN ABOUT THE FAILED OPERATION. IN ANY MOMENT AND WITHOUT
NOTICE FAE FAGAN APPLICAZIONI ELETTRONICHE RESERVES TO CARRY OUT TECHNICAL CHANGES
AIMED AT ENHANCING THE QUALITY OR THE PERFORMANCE OF ITS PRODUCTS.
2 PRELIMINARY INSPECTIONS - WARRANTY
Before installing the controller, make sure that it has not been damaged during the carrying and that it corresponds to
the model ordered. Check that the technical specifications listed in the label match with those written in the delivery
note and in the order form. The controller is covered by a 12-month warranty starting from the delivery. The warranty
covers production defects not due to damaging or wrong use, for goods returned to us EX-WORKS. Any damage
occurred during the carrying shall be reported to the carrier in with the local legislation.
2.1 DISPOSAL
The sign marked on the equipment indicates that it is not to be considered as a normal domestic waste; therefore it
has to be disposed of in a specific electrical and electronic equipment recycling point.
3 XV300K – USE FEATURES
The XV300K electronic controller is normally used to control the speed of AC fans, pumps and centrifugal pumps. It is
based on the principle of symmetrical phase partialisation and It is suitable for adjustable voltage motors. XV300K
operates on the basis of the inputs received through the measurements, the parameters settings values, the
controlling I/O and the control panel. The control panel is used to set the parameters values and read the information
about the unit status. XV300K is provided with Modbus connection to dialog with a supervising remote device.
4 CODING
Position
1
2
3
4
5
6
7
8
XV3
08
K
-6
1
1
2
1
Position
1
Model Family: XV300K
2
Nominal current in Ampere
3
External case: K=boxed
4
Power supply: -6=230-400VAC, -8=440-460VAC (*)
5
1=MASTER
6
IP degree: 1=IP55
7
1=RTC; 2=no RTC
8
Display type: 1=normal display; 2=OLED display
(*) 440-460VAC available only on request
