2.1Onboardkeyboard
TheuserinterfaceconsistsofanonboardkeyboardwithatwolineandsixbuttonLCDdisplay.
Throughthedisplayyoucanviewthevaluesmeasuredbytheunitprobes,thestatusofthephysical
outputsaswellasinformationsabouttheunit(numberofoperatinghours,numberofcompressor
starts)andfaults.Authorizedpersonnelcanaccesstopasswordprotectedparametersprogramming,
e.g.changeunitsettingsorenableadditionalfunctions.Theactivationofthemaincomponents
(compressor,fan,pump,heater)isindicatedbyicons.
lo
adstatus
(compressors,fans,pumps) temperatureunitofmeasure
clo
ck
pressureunito
fmeasure
wo
rkingmodeicons
activefunctio
ns
alarmsandflow
switch
2
2.2Displayandicons
ONwhenatemperatureorpressureisvisualized
Realtimeclock:ONwhenthebottomdisplayshowtheRTC
ONduringtheprogrammingwithtimebasedparametervalue
Infunctionmenuindicatesthedefrostdelaycounting
Generalalarm:blinkingincaseofalarm
ONwhendomestichotwaterproductionisactive
ONindefrost
Blinkingduringdefrostactivationdelay
Antifreezeheaters/integrationheating/boiler:ONiftheheatersareswitchedON
Waterflowalarm:blinkingincaseofwaterflowalarm

Waterpump:ONifatleastonewaterpumpisactive
US
ERINTERFACE
