19
CLARKSON SLURRY KNIFE GATE VALVES
KGA+
Air cylinder actuator
Cylinder mounting washer/nut
Yoke (clevis)
Clevis pin w/cotter pin
Frame (yoke)
Housing/frame (yoke) screw/washer/nut
Hydraulic cylinder actuator
Cylinder mounting washer/nut
Yoke (clevis)
Clevis pin w/cotter pin
Frame (yoke)
Housing/frame (yoke) screw/washer/nut
18 AIR CYLINDER ACTUATOR ASSEMBLY - AC
19 HYDRAULIC CYLINDER ACTUATOR ASSEMBLY - HC
