Emerson Liebert GXT3 User Manual

Installation
10
2.4 Mechanical Installation
The Liebert
®
GXT3
™
may be installed as a tower or in a rack, depending on space and use
considerations. The Liebert GXT3 may be used alone, as a single UPS, or with up to four battery
cabinets.
2.4.1 Tower Installation
To install the Liebert GXT3 as a tower:
1. Take out support bases from the accessories (see Figure 6).
Figure 6 Support bases
2. If optional Liebert external battery cabinets will be connected to the Liebert GXT3, take out the
spacers delivered with the battery cabinet.
3. Connect the spacers and the support bases as shown in Figure 6. Each Liebert GXT3 needs two
assembled support bases, one in the front and one in the rear.
4. Adjust the direction of the operation and display panel and logo on the Liebert GXT3.
a. Remove the front plastic bezel cover (see Figure 7).
Figure 7 Remove the front plastic bezel cover
b. Pull the operation and display panel, rotate it 90 degrees clockwise and snap it back into
position (see Figure 8).
NOTE
When installing the UPS or making input and output connections, comply with all relevant
safety codes and standards.
Support Bases
Spacers
Connectors
Front Plastic
Bezel Cover

Emerson Liebert GXT3 Specifications

General

Model	Liebert GXT3
Relative Humidity	0-95% non-condensing
Type	Online Double Conversion
Input Frequency	50/60 Hz
Output Frequency	50/60Hz ±0.1%
Power Factor	0.9
Form Factor	Tower or Rackmount
Battery Type	Sealed Lead-Acid (SLA)
Communication Interface	RS-232, USB
Operating Temperature	0° to 40°C (32° to 104°F)
Storage Temperature	-15°C to 40°C (5°F to 104°F)
Dimensions	Varies depending on the specific model
Weight	Varies depending on the specific model
Certifications	UL, cUL, CE, RoHS
