Specifications
35
Table 13 Battery cabinet specifications
Parameter
Model Number
GXT3-48VBATT GXT3-72VBATT
Used w/UPS Model
GXT3-700RT230, GXT3-1000RT230,
GXT3-1500RT230, GXT3-2000RT230 GXT3-3000RT230
Dimensions, D x W x H, mm (in)
Unit
497 × 430 × 85
(19.7 x 16.9 x 3.3)
602 × 430 × 85
(23.6 x 16.9 x 3.3)
Shipping
617 x 570 x 262
(24.3x 22.4 x 10.3)
717 x 570 x 262
(28.2 x 22.4 x 10.3)
Weight, kg (lb)
Unit 32 (70.5) 42 (92.6)
Shipping 35 (77.2) 46 (101.4)
Battery parameters
Type Valve-regulated, nonspillable, lead acid
Qty × V× Rating 2 × 4 × 12V × 9.0Ah 2 × 6 × 12V × 9.0Ah
Battery Mfr/Part# Panasonic/UP-RW1245 CSB/HR 1234W F2
Backup Time See Table 15 - Battery run times
Environmental
Operating Temperature 0ºC to 40ºC (32ºF to 104ºF)
Storage Temperature -15ºC to +40ºC (19ºF to 104ºF)
Relative Humidity 0% to 95%, non-condensing
Operating Elevation Up to 3000m (10,000 ft.) at 40ºC (104ºF) without derating
Storage Elevation 15000m (50,000 ft.) maximum
Agency
Safety IEC/EN/AS 62040-1:2008, GS mark
RFI/EMI FCC Part 15, Class A=CISPR22 Class B
Surge Immunity IEC 62040-2 2nd Ed:2006
Transportation ISTA Procedure 1A
Table 14 Operating temperature parameters
Ambient Temperature,
°C (°F)
25-30 (77-86) 30-35 (86-95) 35-40 (95-104)
Maximum Output Power
Factor Derating
@ Maximum Load
100%-93% 93%-86% 86%-79%
