Emerson Micro Motion 1000 Series

Configuration and Use Manual 165
Default Values and Ranges
Diagrams Model 2500 CIOModel 1500 ANDefaults
Variable
mapping
Primary variable Mass flow
Secondary variable • Series 1000:
Mass flow
• Series 2000:
Density
Tertiary variable Mass flow
Quaternary variable • Series 1000:
Mass flow
• Series 2000:
Volume flow
Update rate Update rate Normal Normal or
Special
Normal = 20 Hz
Special = 100 Hz
Primary mA
output
Primary variable Mass flow
LRV –200 g/s See below
URV 200 g/s See below
AO cutoff 0.00000 g/s
AO added damping 0.00000 sec
LSL –200 g/s Read-only
USL 200 g/s Read-only
Min Span 0.3 g/s Read-only
Fault action Downscale
AO fault level – downscale • AN: 2.0 mA
• CIO: 2.0 mA
• IS: 3.2 mA
1.0–3.6 mA
AO fault level – upscale 22.0 mA 21.0–24.0 mA
Last measured value timeout 0.00 sec
Secondary mA
output
Secondary variable Density
LRV 0.00 g/cm
3
See below
URV 10.00 g/cm
3
See below
AO cutoff Not-A-Number
AO added damping 0.00000 sec
LSL 0.00 g/cm
3
Read-only
USL 10.00 g/cm
3
Read-only
Min Span 0.05 g/cm
3
Read-only
Fault action Downscale
AO fault level – downscale • AN: 2.0 mA
• CIO: 2.0 mA
• IS: 3.2 mA
1.0–3.6 mA
AO fault level – upscale 22.0 mA 21.0–24.0 mA
Table A-1 Transmitter default values and ranges continued
Type Setting Default Range Comments
