Flowmeter Installation Types and Components
Diagrams Model 2500 CIOModel 1500 ANDefaults
Figure B-8 Installation types – Model 1700/2700 transmitters
Transmitter
Sensor
Junction box
9-wire cable
9-wire remote
Core processor
(standard only)
4-wire remote
Transmitter
Sensor
Core processor
(standard or enhanced)
4-wire cable
Transmitter
Sensor
Core processor
(standard only)
Integral
Remote core processor with
remote transmitter
4-wire cable
9-wire cable
Sensor
Junction box
Transmitter
Core processor
(standard only)
