176 Micro Motion Series 1000 and Series 2000 Transmitters
Flowmeter Installation Types and Components
Figure B-9 Transmitter and core processor components – Integral installations
Figure B-10 Transmitter components, junction end-cap removed – 4-wire remote and remote core processor
with remote transmitter installations
–
Base
Core processor
Transmitter
Sensor
Transition ring
4 X Cap screws (4 mm)
Ground lug
Mounting bracket
Main enclosure
Junction housing
Mating connector
socket
Mating connector
Junction end-cap
4 X Cap screws
(4 mm)
Conduit opening
for 4-wire cable
