Emerson Micro Motion 1000 Series

Configuration and Use Manual 177
Flowmeter Installation Types and Components
Diagrams Model 2500 CIOModel 1500 ANDefaults
Figure B-11 Transmitter/core processor assembly exploded view – 9-wire remote installations
Figure B-12 Remote core processor components
End-cap
Mounting bracket
Core processor housing
Transmitter
Core processor
4 X Cap screws (4 mm)
Conduit opening
for 9-wire cable
End-cap
Mounting bracket
Core processor lid
Core processor housing
Conduit opening
for 4-wire cable
Conduit opening
for 9-wire cable
4 X Cap screws (4 mm)
