Emerson Micro Motion 1000 Series

Configuration and Use Manual 179
Flowmeter Installation Types and Components
Diagrams Model 2500 CIOModel 1500 ANDefaults
Figure B-15 9-wire cable between sensor junction box and core processor
Figure B-16 Output and power supply terminals – Model 1700/2700 transmitter
9-wire cable 9-wire terminal connections
(core processor)
Brown
Red
Green
White
Blue
Gray
Black
(Drains from all
wire sets)
Brown
Violet
Ye l l o w
Blue
Gray
Orange
Red
Green
White
Mounting
screw
Ground screw
Black
Plug and
socket
Orange
Violet
Yellow
to sensor junction box
Equipment
ground
9 (–, N)
10 (+, L)
1
2
3
4
5
6
Channel A
Channel B
Channel C
Service port
8
7
