Configuration and Use Manual 183
Menu Flowcharts – Model 1500 AN Transmitters
Diagrams Model 2500 CIOModel 1500 ANDefaults
Figure C-2 ProLink II configuration menu
Flow
• Flow direction
•Flow damp
•Flow cal
• Mass flow cutoff
• Mass flow units
• Vol flow cutoff
• Vol flow units
• Vol flow type
• Std gas vol flow cutoff
• Std gas flow units
• Std gas density
Gas wizard
• Mass factor
• Dens factor
• Vol factor
• Flow switch variable
• Flow switch setpoint
• Enable entrained air
handling
Density
• Dens units
• Dens damping
• Slug high limit
• Slug low limit
• Slug duration
• Low density cutoff
•K1
•K2
•FD
•D1
•D2
• Temp coeff (DT)
Temperature
• Temp units
• Temp cal factor
• Temp damping
• External temperature
Analog output
• Primary variable is
• Lower range value
• Upper range value
• AO cutoff
• AO added damp
•LSL
•USL
•Min Span
• AO fault action
• AO fault level
• Last measured value timeout
Frequency
Frequency
• Tertiary variable
• Scaling method
•Freq factor
• Rate factor
• Pulses per unit
• Units per pulse
• Freq pulse width
• Last measured value timeout
• Freq fault action
• Power type
• Freq output polarity
ProLink >
Configuration
Additional configuration options
Pressure
•Flow factor
• Dens factor
• Cal pressure
• Pressure units
RS-485
•Protocol
•Parity
• Baud rate
•Stop bits
