Emerson Micro Motion 1000 Series

Configuration and Use Manual 189
Menu Flowcharts – Model 1500 AN Transmitters
Diagrams Model 2500 CIOModel 1500 ANDefaults
Figure C-9 Communicator detailed setup menu continued
On-Line Menu >
4 Detailed Setup
3
Config outputs
1 AO setup
2 FO setup
3 HART output
4 RS485 setup
5 Fault timeout
1 PV is
2 Range values
3 PV AO cutoff
4 PV AO added damp
5 AO1 fault setup
1
Additional options
1 Poll addr
2 Num preambles
3 Burst mode
4 Burst option
5 Burst var 1
6 Burst var 2
7 Burst var 3
8 Burst var 4
3
1 TV is
2 FO scale method
3 TV freq factor
4 TV rate factor
3 TV pulses/unit
3 TV units/pulse
4/5 Max pulse width
5/6 Polarity
6/7 FO fault indicator
7/8 FO fault value
4
Device information
1 Tag
2 Descriptor
3 Message
4 Date
5 Dev id
6 Final assembly number
7 Sensor s/n
8 Sensor model
9 Output option board
Construction materials
Revision #s
65
Config discrete event
1 Discrete event 1
2 Discrete event 2
3 Discrete event 3
4 Discrete event 4
5 Discrete event 5
Config events
1 Event 1
2 Event 2
1 Event var
2 Event type
3 Event setpoint
4
1 Discrete event var
2 Discrete event type
3 Setpoint A
4 Setpoint B
2
1 RS485 protocol
2 RS485 baudrate
3 RS485 parity
4 RS485 stop bits
5 Modbus address
6 Comm fault ind
