Menu Flowcharts – Model 1500 AN Transmitters
Figure C-10 Communicator detailed setup menu continued
On-Line Menu >
4 Detailed Setup
1 Start sensor zero
2 Reset mass total
3 Reset volume total
4 Reset gas standard volume total
5 Reset all totals
6 Start/stop all totals
Discrete actions
1 Assign discretes
2 Read action assign (read-only)
3 Read action assign ALL (read-only)
1 None
2 Discrete event 1
3 Discrete event 2
4 Discrete event 3
5 Discrete event 4
6 Discrete event 5
7 DI 1
Setup simulation mode
1 Enable/disable
2 Simulate mass flow
3 Simulate temperature
4 Simulate density
7
1
8
1 Fixed value
2 Triangular wave
3 Sine wave
2, 3, 4
