Emerson Micro Motion 1000 Series

Menu Flowcharts – Model 1700/2700 IS Transmitters
Model 1700/2700 IS Display CodesModel 2700 CIOModel 1700/2700 AN
Configuration and Use Manual 227
Figure F-9 Communicator detailed setup menu continued
On-Line Menu >
4 Detailed Setup
3
Config outputs
1 Analog output 1
2 Analog output 2
3 FO/DO config
4 HART output
5 Fault timeout
6 Comm fault ind
1 PV is
2 Range values
3 PV AO cutoff
4 PV AO added damp
5 AO1 fault setup
6 Fix analog out 1
7 Trim analog out 1
8 Scaled AO1 trim
1
Additional options
1 Poll addr
2 Num preambles
3 Burst mode
4 Burst option
5 Burst var 1
6 Burst var 2
7 Burst var 3
8 Burst var 4
3
1 SV is
2 Range values
3 SV AO cutoff
4 SV AO added damp
5 AO2 fault setup
6 Fix analog out 2
7 Trim analog out 2
8 Scaled AO2 trim
1 Freq/DO setup
2 TV is
3 FO scale method
4 TV freq factor
5 TV rate factor
4 TV pulses/unit
4 TV units/pulse
5/6 Max pulse width
6/7 Polarity
7/8 FO fault indicator
8/9 FO fault value
9/ DO is
Flow switch variable
Flow switch setpoint
DO 1 polarity
DO fault indication
4
Device information
1 Tag
2 Descriptor
3 Message
4 Date
5 Dev id
6 Final assembly number
7 Sensor s/n
8 Sensor model
9 Output option board
Construction materials
Revision #s
6
5
Config discrete event
1 Discrete event 1
2 Discrete event 2
3 Discrete event 3
4 Discrete event 4
5 Discrete event 5
Config events
1 Event 1
2 Event 2
1 Event var
2 Event type
3 Event setpoint
4
1 Discrete event var
2 Discrete event type
3 Setpoint A
4 Setpoint B
2
