228 Micro Motion Series 1000 and Series 2000 Transmitters
Menu Flowcharts – Model 1700/2700 IS Transmitters
Figure F-10 Communicator detailed setup menu continued
On-Line Menu >
4 Detailed Setup
1 Start sensor zero
2 Reset mass total
3 Reset volume total
4 Reset gas standard volume total
5 Reset all totals
6 Start/stop all totals
Display setup
1 Enable/disable
2 Display variables
3 Display precision
Discrete actions
1 Assign discretes
2 Read action assign (read-only)
3 Read action assign ALL (read-only)
1 None
2 Discrete event 1
3 Discrete event 2
4 Discrete event 3
5 Discrete event 4
6 Discrete event 5
7 DI 1
Setup simulation mode
1 Enable/disable
2 Simulate mass flow
3 Simulate temperature
4 Simulate density
1 Display total reset
2 Display auto scroll
3 Display offline menu
4 Display alarm menu
5 Display ACK All
6 Display offline password
7 Offline password
7/8 Display total start/stop
8/9 Update period
9/ Backlight control
Display language
LED blinking
Alarm screen password
8
1
1
9
1 Fixed value
2 Triangular wave
3 Sine wave
2, 3, 4
7
