82 Micro Motion Series 1000 and Series 2000 Transmitters
Optional Configuration
A003 Sensor Not Responding (No Tube Interrupt) Fault Yes Yes
Sensor Failure
A004 Temperature Sensor Out-of-Range Fault No Yes
Temperature Sensor Failure
A005 Input Over-Range Fault Yes Yes
Input Overrange
A006 Transmitter Not Characterized Fault Yes No
Not Configured
A008 Density Outside Limits Fault Yes Yes
Density Overrange
A009 Transmitter Initializing/Warming Up Fault Yes No
Transmitter Initializing/Warming Up
A010 Calibration Failure Fault No No
Calibration Failure
A011 Excess Calibration Correction, Zero too Low Fault Yes No
Zero Too Low
A012 Excess Calibration Correction, Zero too High Fault Yes No
Zero Too High
A013 Process too Noisy to Perform Auto Zero Fault Yes No
Zero Too Noisy
A014 Transmitter Failed Fault No No
Transmitter Failed
A016 Line RTD Temperature Out-Of-Range Fault Yes Yes
Line RTD Temperature Out-of-Range
A017 Meter RTD Temperature Out-Of-Range Fault Yes Yes
Meter RTD Temperature Out-of-Range
A018 EEprom Checksum Error Fault No No
(E)EPROM Checksum Error
A019 RAM Test Error Fault No No
RAM or ROM TEST ERROR
A020 Calibration Factors Unentered Fault Yes No
Calibration Factors Unentered (FlowCal)
A021 Unrecognized/Unentered Sensor Type Fault No No
Incorrect Sensor Type (K1)
A022
(1)
(E)EPROM Config. DB Corrupt (Core
Processor)
Fault No No
(E)EPROM Config. CB Corrupt (CP)
A023
(1)
(E)EPROM Totals Corrupt (Core Processor) Fault No No
(E)EPROM Powerdown Totals Corrupt (CP)
Table 8-8 Status alarms and severity levels continued
Alarm code
Communicator message
Default
severity Configurable
Affected by
fault timeoutProLink II message
