Quantum MP User Guide 105
Issue: A4 www.emersonct.com
Parameter
Range(
) Default()
Type
3.01 Final speed reference {di04, 0.39} ±SPEED_MAX rpm RO Bi FI NC PT
3.02 Speed feedback {di05, 0.40} ±SPEED_MAX rpm RO Bi FI NC PT
3.03 Speed error ±SPEED_MAX rpm RO Bi FI NC PT
3.04 Speed controller output {di06, 0.41} ±Torque_prod_current_max % RO Bi FI NC PT
3.05 Zero speed threshold 0 to 200 rpm 30 RW Uni US
3.06 At speed lower limit 0 to 10,000 rpm 5 RW Uni US
3.07 At speed upper limit 0 to 10,000 rpm 5 RW Uni US
3.08 Overspeed threshold 0 to 10,000 rpm 0 RW Uni US
3.09 Absolute ‘at speed’ detect OFF (0) or On (1) OFF (0) RW Bit US
3.10
Speed controller proportional gain
(Kp1)
{SP01, 0.61} 0.0 to 6.5535 (1 / rad/s)) 0.0300 RW Uni US
3.11 Speed controller integral gain (Ki1) {SP02, 0.62} 0 to 655.35 (s / rad/s)) 0.10 RW Uni US
3.12
Speed controller differential
feedback gain (Kd1)
{SP03, 0.63} 0 to 0.65535 (1/s / rad/s)) 0.00000 RW Uni US
3.13 Speed controller proportional gain (Kp2) 0.0 to 6.5535 (1 / rad/s)) 0.0300 RW Uni US
3.14 Speed controller integral gain (Ki2) 0 to 655.35 (s / rad/s)) 0.10 RW Uni US
3.15 Speed controller differential feedback gain (Kd2) 0 to 0.65535 (1/s / rad/s)) 0.00000 RW Uni US
3.16 Speed controller gain select OFF (0) or On (1) OFF (0) RW Bit US
3.17 Speed controller set-up method 0 to 2 0 RW Uni US
3.18 Motor and load inertia
0.0 to 90.00000 kg m
2
0.00000 RW Uni US
3.20 Bandwidth 0 to 50 Hz 1 RW Uni US
3.21 Damping factor 0.0 to 10.0 1.0 RW Uni US
3.22 Hard speed reference
-MAX_SPEED_REF to
MAX_SPEED_REF rpm
0.0 RW Bi US
3.23 Hard speed reference selector OFF (0) or On (1) OFF (0) RW Bit US
3.26 Speed feedback selector {Fb01, 0.71} 0 to 5 5 RW Txt US
3.27 Drive encoder speed feedback {Fb09, 0.79} ±10,000.0 rpm RO Bi FI NC PT
3.28 Drive encoder revolution counter ±32,768 revolutions RO Bi FI NC PT
3.29 Drive encoder position
0 to 65,535 1/2
16
ths of a revolution
RO Uni FI NC PT
3.31 Drive encoder marker position reset disable OFF (0) or On (1) OFF (0) RW Bit US
3.32 Drive encoder marker flag OFF (0) or On (1) OFF (0) RW Bit NC
3.33 Drive encoder turn bits 0 to 16 16 RW Uni US
3.34 Drive encoder lines per revolution {Fb05, 0.75} 1 to 50,000 1024 RW Uni US
3.35 Drive encoder marker mode 0 to 1 0 RW Uni US
3.36 Drive encoder supply voltage {Fb06, 0.76} 0 to 3 0 RW Txt US
3.38 Drive encoder type {Fb07, 0.77} 0 to 2 0 RW Txt US
3.39 Drive encoder termination select {Fb08, 0.78} 0 to 2 1 RW Uni US
3.40 Drive encoder error detection level 0 to 2 0 RW Uni US
3.42 Drive encoder filter 0 to 5 (0 to 16 ms) 2 RW Txt US
3.43 Maximum drive encoder reference 0 to 10,000 rpm 1000 RW Uni US
3.44 Drive encoder reference scaling 0 to 4.000 1.000 RW Uni US
3.45 Drive encoder reference ±100.0% RO Bi FI NC PT
3.46 Drive encoder reference destination 0 to 22.99 0.00 RW Uni DE PT US
3.47 Re-initialise position feedback OFF (0) or On (1) RW Bit NC
3.48 Position feedback initialised OFF (0) or On (1) RO Bit NC PT
3.49 Full motor object electronic nameplate transfer OFF (0) or On (1) OFF (0) RW Bit US
3.50 Position feedback lock OFF (0) or On (1) OFF (0) RW Bit NC
3.51 Tachometer voltage rating {Fb02, 0.72} 0 to 300.00 v/1000rpm Eur:60.00, USA 50.00 RW US
3.52 Tachometer speed feedback {Fb04, 0.74} ±SPEED_MAX rpm RO Bi FI NC PT
3.53 Tachometer input mode {Fb03, 0.73} 0 to 2 0 (DC) RW Txt US
3.54 Encoder direction OFF (0) or On (1) OFF (0) RW Bit US
3.55 Select estimated speed on feedback loss OFF (0) or On (1) OFF (0) RW Bit US
3.56 Speed feedback loss window 0 to 100.0% 20.0% RW US
3.57 Estimated speed has been automatically selected OFF (0) or On (1) RO Bit
3.58 Speed feedback percentage ±100.0% RO NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
