Parameter
Range(
) Default()
Type
5.01 Armature firing angle 0 to 175.0 ° RO Uni FI NC PT
5.02 Armature voltage {di10, 0.45} ±ARMATURE_VOLTAGE_MAX V RO Bi FI NC PT
5.03 Output power ±POWER_MAX kW RO Bi FI NC PT
5.04 Estimated speed ±10,000.0 rpm RO Bi FI NC PT
5.05 Line voltage 0 to 1000V rms AC RO Uni FI NC PT
5.06 Machine armature voltage ±ARMATURE_VOLTAGE_MAX V RO Bi Fl NC PT
5.07 Motor rated current {SE07, 0.28} 0 to RATED_CURRENT_MAX A RATED_CURRENT_MAX RW Uni RA US
5.08 Base speed {SE08, 0.29} 0.0 to 10,000.0 rpm 1,000.0 RW Uni US
5.09 Armature rated voltage {SE06, 0.27} 0 to ARMATURE_VOLTAGE_MAX Vdc
For 480V drive: 440 Eur 500 USA
For 575V drive: 630 Eur 630 USA
For 690V drive: 760 Eur 760 USA
RW Uni RA US
5.10 Direct firing angle 0 to 165.0 ° 165.0 RW Uni
5.11 Direct firing angle enable OFF (0) or On (1) OFF (0) RW Uni US
5.12 Autotune {SE13, 0.34} 0 to 3 0 RW Uni NC
5.13 Continuous Back End Stop 0 to 165.0 ° 165.0 RW Uni US
5.14 Armature voltage select OFF (0) or On (1) OFF (0) RW Bit US
5.15 Motor constant 0 to 100.0% 50.0% RW Uni US
5.16 DC contactor OFF (0) or On (1) ON (1) RW Bit US
5.21 Quadrant 1 Enable 0 to 1 1 RW Uni US
5.22 Quadrant 2 Enable 0 to 1 1 RW Uni RA US
5.23 Quadrant 3 Enable 0 to QUADRANT_MAX 1 RW Uni US
5.24 Quadrant 4 Enable 0 to QUADRANT_MAX 1 RW Uni RA US
5.25 Disable adaptive control OFF (0) or On (1) OFF (0) RW Bit US
5.26 Continuous auto tune OFF (0) or On (1) OFF (0) RW Bit US
5.28 Field weakening compensation disable OFF (0) or On (1) Eur: 0, USA: 1 RW Bit US
5.29 Motor saturation breakpoint 1 0 to 100% of rated flux 50 RW Uni US
5.30 Motor saturation breakpoint 2 0 to 100% of rated flux 75 RW Uni US
5.32 Motor torque per amp
0.000 to 50.000 NmA
-1
RO Uni
5.43 Armature mode 0 to 6 0 RW Txt US
5.45 Bridge request output 0 to 1 RW Bit
5.46
Slave bridge request status 0 to 1
RW Bit
5.47 RW Bit
5.48 RW Bit
5.50 Security unlock 0 to 999 RW Uni NC PT
5.52 IR drop ±ARMATURE_VOLTAGE_MAX Vdc RO Bi FI NC PT
5.53 Back emf ±ARMATURE_VOLTAGE_MAX Vdc RO Bi FI NC PT
5.54 Flux feedback ±150% RO Bi FI NC PT
5.55 Flux demand ±120% RW Bi FI NC PT
5.56 Field current feedback {di09, 0.44} ±50.00 A RO Bi FI NC PT
5.57 Percentage voltage demand ±150.0% RO Bi FI NC PT
5.58 Field firing angle 0 to 180.0 ° RO Uni FI NC PT
5.59 Back emf set point 0 to ARMATURE_VOLTAGE_MAX Vdc For 480V Drive: 440 Eur 500 USA RW Uni US
5.61 Armature Resistance 0 to 6.0000 0.0000 RW Uni US
5.62 Spill over loop P gain 0 to 300.00 0.40 RW Uni US
5.63 Spill over loop I gain 0 to 300.00 5.00 RW Uni US
5.65 Enable economy timeout 0 to 1 Eur: 0, USA: 1 RW Bit US
5.67 Field economy level 0 to 120.0% 25.0% RW Uni US
5.68 Maximum flux 0 to 120.0% 100.0% RW Uni US
5.69 Minimum flux 0 to 120.0% 50.0% RW Uni US
5.70 Rated field current {SE10, 0.31} 0 to FIELD_CURRENT_SET_MAX Size 1-Eur: 2A, USA: 8A RW Uni RA PT US
5.71 Flux loop P gain 0 to 300.00 3.00 RW Uni PT US
5.72 Flux loop I gain 0 to 300.00 60.00 RW Uni US
5.73 Rated field voltage {SE11, 0.32} 0 to 500.0 Vdc Eur: 360, USA: 300 RW Uni US
5.74 Rated field compensation factor 0 to 100% 100% RW Uni PT US
5.75 Field voltage mode select OFF (0) or On (1) Eur: 0, USA: 1 RW Bit US
5.76 Auxiliary supply 0 to 550 rms Vac RO Uni FI NC PT
5.77 Enable field control {SE12, 0.33} OFF (0) or On (1) OFF (0) RW Txt US
5.78 Field mode IntrnL (0), EtrnL (1), E FULL (2) IntrnL (0) RW Txt US
5.79 Economy active OFF (0) or On (1) RO Bit
5.80 Economy level select OFF (0) or On (1) OFF (0) RW Bit US
5.81 Field thermal time constant 0 to 3000.0 24.0 RW Uni US
5.82 Field overload accumulator 0 to 100.0% RO Uni NC PT
5.83 Field reversal enable 0 to ONLY_2_QUADRANT 0 RW Uni RA US
5.84 Field flux threshold 0 to 100% 75% RW Uni US
5.85 Flux demand invert 0 to 1 RO Bit NC PT
5.86 Speed error invert 0 to 1 RO Bit NC PT
