Quantum MP User Guide 113
Issue: A4 www.emersonct.com
Parameter
Range(
) Default()
Type
6.01 Stop mode 0 to 2 1 RW Uni US
6.03 Main loss ride through OFF (0) or On (1) OFF (0) RW Bit US
6.04 Start/stop logic select 0 to 4 4 RW Uni US
6.08 Hold zero speed OFF (0) or On (1) OFF (0) RW Bit US
6.09 Catch a spinning motor 0 to 1 1 RW Uni US
6.12 Enable stop key OFF (0) or On (1) OFF (0) RW Bit US
6.13 Enable forward/reverse key 0 to 2 0 RW Uni US
6.15 Drive enable OFF (0) or On (1) On (1) RW Bit US
6.16 Electricity cost per kWh 0 to 600.0 currency units per kWh 0.0 RW Uni US
6.17 Reset energy meter OFF (0) or On (1) OFF (0) RW Bit NC
6.18 Time between filter changes 0 to 30,000 hrs 0 RW Uni US
6.19 Filter change required / change done OFF (0) or On (1) OFF (0) RW Bit PT
6.20 Powered-up time: years.days 0 to 9.364 Years.Days RW Uni NC PT
6.21 Powered-up time: hours.minutes 0 to 23.59 Hours.Minutes RW Uni NC PT
6.22 Run time: years.days 0 to 9.364 Years.Days RO Uni NC PT PS
6.23 Run time: hours.minutes 0 to 23.59 Hours.Minutes RO Uni NC PT PS
6.24 Energy meter: MWh ±9999 MWh RO Bi NC PT PS
6.25 Energy meter: kWh ±999 kWh RO Bi NC PT PS
6.26 Running cost ±32000 RO Bi FI NC PT
6.27 Time before filter change due 0 to 30,000 hrs RO Uni NC PT PS
6.28 Select clock for trip log time stamping OFF (0) or On (1) OFF (0) RW Bit US
6.29 Hardware enable OFF (0) or On (1) RO Bit NC PT
6.30 Sequencing bit: Run forward OFF (0) or On (1) OFF (0) RW Bit NC
6.31 Sequencing bit: Jog OFF (0) or On (1) OFF (0) RW Bit NC
6.32
Sequencing bit: Run/reverse
OFF (0) or On (1) OFF (0) RW Bit NC
6.33 Sequencing bit: Forward/reverse OFF (0) or On (1) OFF (0) RW Bit NC
6.34 Sequencing bit: Run OFF (0) or On (1) OFF (0) RW Bit NC
6.35 Forward limit switch OFF (0) or On (1) OFF (0) RW Bit NC
6.36 Reverse limit switch OFF (0) or On (1) OFF (0) RW Bit NC
6.37 Sequencing bit: Jog reverse OFF (0) or On (1) OFF (0) RW Bit NC
6.39 Sequencing bit: Not stop OFF (0) or On (1) OFF (0) RW Bit NC
6.40 Enable sequencer latching OFF (0) or On (1) On (1) RW Bit US
6.41 Drive event flags 0 to 65535 0 RW Uni NC
6.42 Control word 0 to 32767 0 RW Uni NC
6.43 Control word enable OFF (0) or On (1) OFF (0) RW Bit US
6.45 Force cooling fan to run at full speed OFF (0) or On (1) RW Bit US
6.50 Drive comms state 0 to 3 RO Txt NC PT
6.52 Zero reference interlock OFF (0) or On (1) OFF (0) RW Bit US
6.54 Run rising edge delay 0 to 25.0s 0.0 RW Uni US
6.55 Contactor enable OFF (0) or On (1) RO Bit NC PT
6.56 Drive active falling edge delay 0 to 255 30s RW Uni US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
