Quantum MP User Guide 115
Issue: A4 www.emersonct.com
Parameter
Range(
) Default()
Type
7.01 T5/6 analog input 1 {in02, 0.82} ±100.00% RO Bi NC PT
7.02 T7 analog input 2 {in03, 0.83} ±100.0% RO Bi NC PT
7.03 T8 analog input 3 {in04, 0.84} ±100.0% RO Bi NC PT
7.04 Power circuit temperature -128°C to 127°C RO Bi NC PT
7.08 T5/6 analog input 1 scaling 0 to 40.000 1.000 RW Uni US
7.09 T5/6 analog input 1 invert OFF (0) to On (1) OFF (0) RW Bit US
7.10 T5/6 analog input 1 destination Pr 0.00 to 22.99 Pr 1.36 RW Uni PT US
7.11 T7 analog input 2 mode 0 to 9 6 RW Uni US
7.12 T7 analog input 2 scaling 0 to 40.000 1.000 RW Uni US
7.13 T7 analog input 2 invert OFF (0) to On (1) OFF (0) RW Bit US
7.14 T7 analog input 2 destination Pr 0.00 to 22.99 Pr 1.37 RW Uni PT US
7.15 T8 analog input 3 mode {in01, 0.81} 0 to 9 Eur: 8 USA:6 RW Txt US
7.16 T8 analog input 3 scaling 0 to 40.000 1.000 RW Uni US
7.17 T8 analog input 3 invert OFF (0) to On (1) OFF (0) RW Bit US
7.18 T8 analog input 3 destination
Pr 0.00 to Pr 22.99
Pr 0.00 RW Uni PT US
7.19 T9 analog output 1 source Pr 3.02 RW Uni PT US
7.20 T9 analog output 1 scaling 0.000 to 40.000 1.000 RW Uni US
7.21 T9 analog output 1 mode 0 to 3 0 RW Txt US
7.22 T10 analog output 2 source Pr 0.00 to Pr 22.99 Pr 4.02 RW Uni PT US
7.23 T10 analog output 2 scaling 0.000 to 40.000 1.000 RW Uni US
7.24 T10 analog output 2 mode
0 to 3
0 RW Txt US
7.28 T7 analog input current loop loss 2 OFF (0) to On (1) RO Bit NC PT
7.29 T8 analog input current loop loss 3 OFF (0) to On (1) RO Bit NC PT
7.30 T5/6 analog input 1 offset ±100.00% 0.00 RW Bi US
7.31 T7 analog input 2 offset ±100.0% 0.0 RW Bi US
7.32 T8 analog input 3 offset ±100.0% 0.0 RW Bi US
7.34 SCR / Thyristor junction temperature 0 to 150°C RO Uni NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
