Quantum MP User Guide 119
Issue: A4 www.emersonct.com
Parameter
Range(
) Default()
Type
8.01 T24 digital I/O 1 state {in05, 0.85} OFF (0) or On (1) RO Bit NC PT
8.02 T25 digital I/O 2 state {in06, 0.86} OFF (0) or On (1) RO Bit NC PT
8.03 T26 digital I/O 3 state {in07, 0.87} OFF (0) or On (1) RO Bit NC PT
8.04 T27 digital input 4 state {in08, 0.88} OFF (0) or On (1) RO Bit NC PT
8.05 T28 digital input 5 state {in09, 0.89} OFF (0) or On (1) RO Bit NC PT
8.06 T29 digital input 6 state {in10, 0.90} OFF (0) or On (1) RO Bit NC PT
8.07 T51, 52, 53 relay state OFF (0) or On (1) RO Bit NC PT
8.09 T31 drive enable state OFF (0) or On (1) RO Bit NC PT
8.10 Enable mode select 0 to 2 0 RW Uni US
8.11 T24 digital I/O 1 invert OFF (0) or On (1) OFF (0) RW Bit US
8.12 T25 digital I/O 2 invert OFF (0) or On (1) OFF (0) RW Bit US
8.13 T26 digital I/O 3 invert OFF (0) or On (1) OFF (0) RW Bit US
8.14 T27 digital input 4 invert OFF (0) or On (1) OFF (0) RW Bit US
8.15 T28 digital input 5 invert OFF (0) or On (1) OFF (0) RW Bit US
8.16 T29 digital input 6 invert OFF (0) or On (1) OFF (0) RW Bit US
8.17 T51, 52, 53 relay invert OFF (0) or On (1) OFF (0) RW Bit US
8.20 Digital I/O read word 0 to 4095 RO Uni NC PT
8.21 T24 digital I/O 1 source/ destination Pr 0.00 to 22.99 Pr 10.06 RW Uni DE PT US
8.22 T25 digital I/O 2 source/ destination Pr 0.00 to 22.99 Pr 0.00 RW Uni DE PT US
8.23 T26 digital I/O 3 source/ destination Pr 0.00 to 22.99 Pr 0.00 RW Uni DE PT US
8.24 T27 digital input 4 destination Pr 0.00 to 22.99 Pr 0.00 RW Uni DE PT US
8.25 T28 digital input 5 destination Pr 0.00 to 22.99 Pr 1.41 RW Uni DE PT US
8.26 T29 digital input 6 destination Pr 0.00 to 22.99 Pr 0.00 RW Uni DE PT US
8.27 T51, 52, 53 relay source Pr 0.00 to 22.99 Pr 10.01 RW Uni PT US
8.29 I/O polarity select 2 1 RW Uni PT US
8.30 Open collector output OFF (0) or On (1) OFF (0) RW Bit US
8.31 T24 digital I/O 1 output select OFF (0) or On (1) On (1) RW Bit US
8.32 T25 digital I/O 2 output select OFF (0) or On (1) OFF (0) RW Bit US
8.33 T26 digital I/O 3 output select OFF (0) or On (1) OFF (0) RW Bit US
8.40 T61, 62, 63 relay state OFF (0) or On (1) RO Bit NC PT
8.41 Start button state OFF (0) or On (1) RO Bit NC PT
8.42 Forward/reverse button state OFF (0) or On (1) RO Bit NC PT
8.48 24V input state OFF (0) or On (1) RO Bit NC PT
8.50 T61, 62, 63 relay invert OFF (0) or On (1) OFF (0) RW Bit US
8.52 Toggle enable OFF (0) or On (1) OFF (0) RW Bit US
8.60 T61, 62, 63 relay destination Pr 0.00 to 22.99 Pr 6.55 RW Uni DE PT US
8.61 Start button destination Pr 0.00 to 22.99 Pr 0.00 RW Uni DE PT US
8.62 Forward/reverse button destination Pr 0.00 to 22.99 Pr 0.00 RW Uni DE PT US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
