Reference Manual
00809-0100-4716, Rev JA
May 2008
Rosemount 3095 MultiVariable
2-16
Table 2-2. Bolt Installation
Torque Values.
NOTE
Only use bolts supplied with the 3095 or sold by Rosemount Inc. as a spare
part to the 3095. Unauthorized parts can affect product performance and may
render the instrument dangerous.
When installing the transmitter to one of the mounting brackets, torque the
mounting bracket bolts to 125 in-lb (14 n-m).
NOTE
All four flange bolts must be installed and tight before applying pressure, or
process leakage will result. When properly installed, the flange bolts will
protrude through the top of the module housing. Attempting to remove the
flange bolts while the transmitter is in service will result in leakage of the
process fluid.
Process Connections 3. Connect the transmitter to the process.
Bolt Material Initial Torque Value Final Torque Value
Carbon Steel (CS) 300 in-lb (34 n-m) 650 in-lb (73 n-m)
Stainless Steel (SST) 150 in-lb (17 n-m) 300 in-lb (34 n-m)
