Table 2-2: Mounting Flange
Diameter ANSI (5R10244H01) DIN (5R10244H02)
Flange diameter 6.00 in. (152 mm) 7.28 in. (185 mm)
Hole diameter 0.75 in. (19 mm) 0.71 in. (18 mm)
4 holes equally spaced on
B.C. diameter
4.75 in. (121 mm) 5.71 in. (145 mm)
Table 2-3: Installation/Removal
Probe Dimension A Dimension B
18 in. (457.2 mm) 18 in. (457 mm) 34 in. (864 mm)
3 ft. (0.9 m) 36 in. (914 mm) 52 in. (1321 mm)
6 ft. (1.8 m) 72 in. (1829 mm) 88 in. (2235 mm)
9 ft. (2.7 m) 108 in. (2743 mm) 124 in. (3150 mm)
Procedure
1. Ensure all components are available to install the transmitter.
You may install the transmitter intact as it is received.
2. Weld or bolt adapter plate onto the duct.
