Emerson Process Management GmbH & Co. OHG 1-5
X-STREAM Non-Incendive
Instruction Manual
HASXENE-IM-EX
12/2014
1
Technical Description
1.3.3 General Technical Data
1.3 Technical data
XEFN XDFN
Temperatures
operational, max.
*)
0 (-20)…+50 °C / 32 (-4)…122 °F
storage -20…+70 °C / -4…-158 °F
Weight, max
up to approx.
25 kg / 55.1 lb
up to approx.
45 kg / 99.2 lb
IP or Type rating
IP 66, Type 4X for outdoor use,
but protected against direct sun light
Measurement channels, max. 5
Gas connections
max number 8
max for purging (incl. / separate) 1 separate
material stainless steel
sizes 6/4 mm;
1
⁄4"
Power supply unit wide range, internal
Power supply
Mains supply voltage fl uctuations are not to exceed
±10 percent of the nominal voltage
nominal voltage 100–240 V
50 / 60 Hz
voltage range 85–264 V
47–63 Hz
nominal input current, max
standard, max 1.3–0.7 A 1.5–0.8 A
w/ temperature control, max 3–1.5 A 5.5–3 A
Power input fuses AC 230 V / T 6.3 A / 5x20 mm
Electrical in- and outputs
power
screw terminals with integrated fuse holders,
max. 4 mm² / AWG 11
signals screw terminals, max. 1.5 mm² / 15 AWG
special Ethernet: RJ45 socket; USB connectors
Cable entries Cable glands, IP 68
permissible cable outer dia 7…12 mm / 0.27"…0.47"
*)
: Limitations apply to selected measurement principles and ranges,
Measurement specifi cations!
