Emerson Process Management GmbH & Co. OHG 1-7
X-STREAM Non-Incendive
Instruction Manual
HASXENE-IM-EX
12/2014
1
Technical Description
Fig. 1-3: X-STREAM XDFN - dimensions
All dimensions in mm
[inches in brackets]
Cable glands
Connector
for potential
equalization
Gas fi ttings
eq
q
q
q
q
q
q
q
q
q
q
q
q
u
u
u
u
u
u
u
1.4 Dimensions
