2- Generator & Load Page:
GENERATOR & LOAD
L12: 380Vac I1: 126A
Fq:50.0Hz
Sp:2000Rpm
AUTO
L23: 380Vac I2: 126A
L31: 380Vac I3: 126A
IT: 378A
IEA: 63A
CRANKNG ATTEMP
PREALARM!OVER SPEED
• L12 - Generator voltage L1-L2
• L23 - Generator voltage L2-L3
• L31 - Generator voltage L3-L1
• Fq - Generator frequency (if enabled).
• Sp - Engine Rpm (if enabled).
• I1 - Load current L1
• I2 - Load current L2
• I3 - Load current L3
• IT – Vectorel total current
• IEA - Earth current
3- Mains Page:
MAINS
L1: 220 L12: 380Vac
L-L AVERAGE: 380Vac
L2: 220 L23: 380Vac
L3: 220 L31: 380Vac
AUTO CRANKNG ATTEMP
PREALARM!OVER SPEED
L-N AVERAGE: 220Vac
• L1 - Mains voltage L1-N
• L2 - Mains voltage L2-N
• L3 - Mains voltage L3-N
• L12 - Mains voltage L1-L2
• L23 - Mains voltage L2-L3
• L31 - Mains voltage L3-L1
• L-L AVERAGE – Phase to phase average
• L-N AVERAGE – Phase to neutral average
