4- Generator Page:
GENERATOR
L1: 220 L12: 380Vac
L-L AVERAGE: 380Vac
L2: 220 L23: 380Vac
L3: 220 L31: 380Vac
AUTO CRANKNG ATTEMP
PREALARM!OVER SPEED
L-N AVERAGE: 220Vac
• L1 - Generator voltage L1-N
• L2 - Generator voltage L2-N
• L3 - Generator voltage L3-N
• L12 - Generator voltage L1-L2
• L23 - Generator voltage L2-L3
• L31 - Generator voltage L3-L1
• L-L AVERAGE – Phase to phase average
• L-N AVERAGE – Phase to neutral average
5- Active Power&Energy Page:
ACTIVE POWER&ENERGY
P1
TOTAL
ENRGY
: 170kW
AUTO CRANKNG ATTEMP
OVER SPEED PREALARM!
P2: 170kW
P3: 170kW
: 510kW
: 30600kWh
• P1 - Generator active power L1
• P2 - Generator active power L2
• P3 - Generator active power L3
• TOTAL - Generator total active power
• ENRGY - Generator active energy
6- Apparent Power Page:
APPARENT POWER
S1
TOTAL
: 210kVA
AUTO CRANKNG ATTEMP
OVER SPEED PREALARM!
S2: 210kVA
S3: 210kVA
: 630kVA
• S1 - Generator apparent power L1
• S2 - Generator apparent power L2
• S3 - Generator apparent power L3
• TOTAL - Generator total apparent power
