7- Reactive Power&Energy Page:
REACTIVE POWER&ENERGY
Q1
TOTAL
ENRGY
: 40kVAr
AUTO CRANKNG ATTEMP
OVER SPEED PREALARM!
Q2: 40kVAr
Q3: 40kVAr
: 120kVAr
: 7200kVArh
• Q1 - Generator reactive power L1
• Q2 - Generator reactive power L2
• Q3 - Generator reactive power L3
• TOTAL - Generator total reactive power
• ENRGY - Generator reactive energy
8- Power Factor Page:
POWER FACTOR
PF1 :-0.84
AUTO CRANKNG ATTEMP
OVER SPEED PREALARM!
PF2:-0.80
PF3:-0.82
• PF1 - Generator power factor L1
• PF2 - Generator power factor L2
• PF3 - Generator power factor L3
9- Anologue Page:
ANALOGUE
OIL PRESS. : 4.3Bar
TEMPERATURE: 30ºC
LEVEL : 16%
BATTERY VOL:18.0Vdc
CHR.GEN.VOL:18.0Vdc
AUTO CRANKNG ATTEMP
OVER SPEED PREALARM!
• BATTERY VOL - Battery voltage
• CHR.GEN.VOL - Charge generator voltage
• OIL PRESS. - Engine Oil pressure (if enabled).
• TEMPERATURE - Coolant temperature (if enabled).
• LEVEL - Fuel Level (if enabled).
