EAOM-210 FLJ.eng / ver 0.0
Pages 42 / 132
NOMINAL FREQUENCY
This parameter used for calculate the engine speed (Rpm) from alternator frequency or
calculate the alternator frequency from engine speed (Rpm).
NOMINAL SPEED
This parameter used for calculate the engine speed (Rpm) from alternator frequency or
calculate the alternator frequency from engine speed (Rpm).
VOLTAGE TRANSFORMER RATIO
1-50: Defines the scaling factor applied to voltage readout and associated fault conditions.
This VT ratio is for additional voltage transformers mounted the unit.
(ENGINE STAR.OPT PAGE) ENGINE STARTING OPTIONS page
AU.ALR.PRIOR STRT.E Audible Alarm Prior To Starting En/Dis
- ENAB DIS DIS
NUMBR OF STR.ATTEMP Number Of Start Attempts
- 1 – 10 3
CRANKING TIME Cranking Time
SEC 1 – 99 5
CRANK REST TIME Crank Rest Time
SEC 5 – 99 10
MUL.STR.ENG.ATEMP.E Multiple Start Engage Attempts E/D (Pick)
PICK.SNSR FAIL DELY Pickup Sensor Fail Delay(Pickup)
SEC 0.1 – 10.0 1.0
AUDIBLE ALARM PRIOR TO STARTING EN/DIS
ENABLE: The audible alarm will sound before the engine starts. The sounder will become
active once the start delay is initialised, it will remain active until either the engine reaches
crank disconnect speed or pre-heat timers are cancelled.
NUMBER OF START ATTEMPTS
This value is the number of times the module will attempt to start the generator. Should the
generator start the module will not attempt further starts. If the generator does not start after
the final attempt, the module will give a ‘Fail to start’ alarm.
CRANKING TIME
This is the maximum amount of time that the module will energise the starter motor for during
starting attempts once the starter has engaged.
CRANK REST TIME
This is the amount of time the module will wait for between start attempts. This is to allow the
starter motor to cool and the starter batteries to recover.
MULTIPLE START ENGAGE ATTEMPTS E/D
(Only available if using Magnetic pickup)
ENABLE: The module will monitor the flywheel to ensure that the starter motor has engaged.
If it detects the starter has not meshed, it will de-energise the start relay and after a short
delay it will attempt to re-engage the starter. This will be repeated until either the starter
motor engages correctly or the number of engage attempts expires. Each start attempt can
have a maximum number of attempts to engage the starter, this value is entered the box.
DISABLE: Normal operation, starter engagement with flywheel will not monitored.
ENGAGE ATTEMPT TIME
(Only available if using Magnetic pickup and multiple engage attempts)
This timer dictates the duration that the module will attempt to engage the starter motor
during each engage attempt. If the magnetic pickup is not detecting movement of the
flywheel when this timer expires the engage attempt will terminate. Once all engage attempts
have been made the module will generate ‘Fail to engage’ alarm.
